Fiberglass Protable Switch Rod High Voltage Brake Pull Rod
Product Details:
| Place of Origin: | Ningbo, China |
| Brand Name: | Suntech |
| Certification: | ISO9001 |
| Model Number: | KV |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 1000 PCS/Month |
|
Detail Information |
|||
| Name: | Switch Rod | Rated Voltage: | 10-500KV |
|---|---|---|---|
| Total Length: | 3-10M | Node Number: | 3/4/5 |
| Combining Ways: | Flat Mouth Spiral / Telescopic | Warranty: | 1 Year |
| Highlight: | Fiberglass Switch Rod,protable Switch Rod,High Voltage Brake Pull Rod |
||
Product Description
Switch Rod Fiberglass Ultraprotable High Voltage Brake Pull Rod
About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either
Application
Pull rod is suitable for high voltage switch out operating. They are produced from epoxy resin, super
light,high voltage, high strength. The length and sections can be made depending on your request.
Advantage
1.Round Shape & High Visibility
2.Easy Maintenance & redesign Lock Buttons
3.Easy Disassemble & Ergonomic Design
4.New Base Cap & More versatile
5.Improved Universal Head
Technical Data
| Rated voltage |
Total length |
Node number |
Retraction length |
Top rod rough |
rod rough |
Combining ways |
| 10KV | 3 | 3 | 124cm | 26mm | 38mm | Telescopic |
| 10KV | 4 | 3 | 158cm | 26mm | 39mm | |
| 35KV | 4 | 4 | 158cm | 26mm | 44mm | |
| 110KV | 5 | 4 | 159cm | 26mm | 44mm | |
| 110KV | 6 | 4 | 184cm | 26mm | 44mm | |
| 220KV | 7 | 4 | 225cm | 26mm | 44mm | |
| 220KV | 9 | 4 | 232cm | 26mm | 45mm | |
| 500KV | 10 | 5 | 241cm | 26mm | 51mm |
