Copper Grounding Block for Low Resistance with 100A Max Current and 50mm Bottom Diameter in Power Systems
Product Details:
| Place of Origin: | Ningbo |
| Brand Name: | Suntech |
| Certification: | ISO |
| Model Number: | SJL-100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case |
| Delivery Time: | 3-7days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 3000 PCS/Month |
|
Detail Information |
|||
| Name: | Grounding Block | Model: | SJL-100 |
|---|---|---|---|
| Bottom Diameter: | 50mm | Applicable Wire: | 40mm |
| Max Current: | 100A | Weight: | 10KG |
| Highlight: | Low Resistance Grounding Block,100A Max Current Copper Grounding Block,50mm Bottom Diameter Electrical Grounding Block |
||
Product Description
Copper Grounding Block for Low Resistance Grounding in Power Distribution and Transmission Systems
| Item number | Model |
Bottom Diameter (mm) |
Applicable Wire |
Max Current (A) |
Sheave Material |
Weight (kg) |
| 12101 | SJL38-100 | Φ46 |
Φ38 Conductor |
100 | Casting steel | 8.9 |
| 12101A | SJL48-100 | Φ56 |
Φ48 Conductor |
100 | Casting steel | 10.0 |
| 12102 | SJT38-100 | Φ46 |
Φ38 Steel wire ropeGrounding Wire |
100 | Casting steel | 11.0 |
A Grounding Block is a fundamental and critical component in any electrical safety system, designed to create a permanent, low-resistance, and mechanically secure connection between grounding conductors, ground rods, equipment frames, and grounding busbars. It serves as the central junction point where individual grounding wires converge and are bonded together, ensuring that all conductive parts of an electrical installation are effectively connected to the earth grounding electrode system. Constructed from high-conductivity materials like copper or bronze, and often featuring corrosion-resistant coatings, the grounding block's primary function is to provide a reliable and inspectable point for grounding connections, which is essential for personal safety, equipment protection, and the proper operation of overcurrent protective devices. In power distribution, transmission, telecommunications, and lightning protection, the grounding block is the unsung hero that ensures fault currents have a safe path to earth, thereby preventing electric shock, fire hazards, and equipment damage.
-
Essential for Electrical Safety and Personnel Protection: The core purpose of a grounding block is to save lives. By providing a robust, low-impedance connection to earth, it ensures that in the event of a fault—such as a live conductor touching equipment casing—the dangerous current is immediately diverted safely into the ground. This rapid diversion causes the circuit breaker or fuse to trip, de-energizing the fault and preventing the metal enclosure from becoming energized, which could electrocute anyone who touches it.
-
Creates a Centralized and Organized Grounding Point: Instead of having multiple ground wires haphazardly connected to a rod or bus, the grounding block provides a single, organized termination point. This simplifies installation, inspection, and testing. All connections are visible and accessible, making it easy for electricians and inspectors to verify the integrity of the grounding system, which is a requirement of all electrical safety codes.
-
Ensures Low Resistance and High Conductivity: Grounding blocks are manufactured from materials with excellent electrical conductivity, such as high-purity copper or copper alloys. This minimizes the resistance of the connection point itself. A low-resistance path is critical because it allows sufficient fault current to flow to quickly trip the protective device. A high-resistance connection can impede current flow, leaving the fault energized and creating a major shock and fire hazard.
-
Provides a Secure and Permanent Mechanical Connection: A proper ground connection must remain secure for the life of the installation, despite vibration, thermal cycling, and environmental stress. Grounding blocks are designed with heavy-duty set screws, compression lugs, or bolted connections that clamp the conductors with tremendous force. This prevents loosening over time, maintaining a gas-tight connection that resists corrosion and ensures ongoing electrical continuity.
-
Facilitates System Testing and Maintenance: A key feature of a professional grounding block is that it allows for the disconnection of individual ground wires without disturbing the entire system. This is vital for periodic testing of ground resistance using a clamp-on ground tester or for isolating sections of the system for troubleshooting. Test points are often integrated into the block's design.
-
Critical for Lightning Protection and Surge Dissipation: In grounding systems for lightning rods and surge protective devices (SPDs), the grounding block is the collection point for massive surge currents. It must handle extremely high, instantaneous currents without failing or overheating, safely directing this energy into the grounding electrode system and away from protected structures and equipment.
-
Durable and Corrosion Resistant for Long Life: Since grounding is a permanent, life-safety installation, the block must last for decades. High-quality blocks are made from corrosion-resistant materials or are plated with tin, nickel, or hot-dip galvanized finishes. This protects the critical connection from oxidation and galvanic corrosion, especially in damp, salty, or industrial environments, ensuring the grounding system remains effective over time.
-
Versatile for Various Applications and Wire Sizes: Grounding blocks are available in configurations to accept a wide range of conductor sizes and types, from small equipment grounding wires to large main bonding jumpers. They can be used in electrical panels, at the base of ground rods, in telecommunications cabinets, on tower bases, and within industrial control systems.
-
Mandatory for Code Compliance and Insurance: The use of listed and labeled grounding blocks is a requirement of the National Electrical Code (NEC) and other international standards for creating code-compliant grounding and bonding connections. Proper installation with certified components is also typically mandated by insurance providers to validate coverage for electrical systems.
-
A Foundational Investment in System Integrity and Reliability: The grounding block is a relatively low-cost component that plays an outsized role in the safety and performance of a multi-million dollar electrical installation. Investing in a high-quality, properly sized grounding block is an investment in risk mitigation, operational uptime, and the long-term reliability of the entire electrical infrastructure.
In summary, the Grounding Block is much more than a simple connector; it is the critical nexus of a safe electrical system. It is the guaranteed meeting point where safety is physically wired into the infrastructure, providing the dependable path that ensures dangerous electricity is always directed away from people and equipment, and safely into the ground where it belongs.
