916 Series Large Diameter Rope Pulley ACSR720 Conductor Nylon Sheaves For Wire Rope
Product Details:
| Place of Origin: | Ningbo, China |
| Brand Name: | Suntech |
| Certification: | ISO9001 |
| Model Number: | SHDN916 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 1000 PCS/Month |
|
Detail Information |
|||
| Name: | 916 Serise Stringing Block | Sheave: | 1/3/5 |
|---|---|---|---|
| Rated Load: | 50-150KN | Weight: | 51-200KG |
| Sheave Features: | MC Nylon Sheave | Warranty: | 1 Year |
| Explain: | Maximum Suitable Conductor ACSR720 | ||
| Highlight: | 916 Series Large Diameter Rope Pulley,ACSR720 Large Diameter Rope Pulley,ACSR720 nylon sheaves for wire rope |
||
Product Description
916 Series Stringing Block Customizable Overhead Transmission Line Tools for ACSR720 Conductor
About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either
1.Maximum suitable conductor ACSR720.
2.Sheave dimension ( outside diameter× root diameter × sheave width) Φ916×Φ800×110(mm).
3.The middle sheave can be customized as cast steel sheave
916mm Main Specifications
| Item Number | Model | Number of Sheave | Rated Load(KN) | Weight(kg) | Sheave Feature |
| 10151 | SHDN916 | 1 | 50 | 51 | MC nylon sheave |
| 10152 | SHSQN916 | 3 | 75 | 120 | MC nylon sheave |
| 10153 | SHWQN916 | 5 | 150 | 200 | MC nylon sheave |
| 10151 | SHDN916-125 | 1 | 50 | 60 | MC nylon sheave |
