Sitting Hanging Type Universal Conductor Stringing Blocks Single Nylon Sheave
Product Details:
| Place of Origin: | Ningbo, China |
| Brand Name: | Suntech |
| Certification: | ISO9001 |
| Model Number: | SHG-0.5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 1000 PCS/Month |
|
Detail Information |
|||
| Name: | Sitting And Hanging Type Dual-Use Stringing BLock | Item No.: | 10261-10274 |
|---|---|---|---|
| Rated Load: | 5-20KN | Sheave Size: | 80x50mm-160x40mm |
| Weight: | 1.95-3.6KG | Remarks: | Aluminum Sheave Or Nylon Sheave |
| Warranty: | 1 Year | Uses: | Product Can Be Used Cither Hanging Type Stringing Block Or Skyward Stringing Block. |
| Highlight: | Sitting Conductor Stringing Blocks,Hanging Conductor Stringing Blocks,universal stringing block Single Nylon |
||
Product Description
Sitting And Hanging Type Dual-Use Single Nylon Sheave Conductor Stringing Block
Application:
SHD Series Single Nylon Sheave Stringing Block Pulley Aerial Cable Blocks
The block is used for conductor stringing operation. It could be used for suspension with the hook fitting, or used on cross arms.This stringing pulley block has the aluminum sheave and nylon sheave, the rated load is from 5KN to 20KN, very light weight, it from1.9kg to 2.5kg, we have the standard sizes as above.
Nylon Sheave Stringing Pulley Block with Hook Data
| Item number | Model | Outside diameter ×width (mm) | Rated load (kN) | Weight (kg) | Remark |
| 10261 | SHC-80×50 | Φ80×50 | 5 | 1.9 | Aluminum sheave |
| 10262 | SHC-120×30 | Φ120×30 | 5 | 2.1 | |
| 10263 | SHC-160×40 | Φ160×40 | 10 | 2.5 | |
| 10264 | SHC-120×58 | Φ120×58 | 20 | 3.5 | |
| 10271 | SHCN-80×50 | Φ80×50 | 5 | 1.4 | Nylon sheave |
| 10272 | SHCN-120×30 | Φ120×30 | 5 | 1.6 | |
| 10273 | SHCN-160×40 | Φ160×40 | 10 | 2 | |
| 10274 | SHCN-120×58 | Φ120×58 | 20 | 2.5 |
