1250 - 2240mm Hydraulic Conductor Drum Stand For Construction Safety
Product Details:
| Place of Origin: | Ningbo, China |
| Brand Name: | Suntech |
| Certification: | ISO9001 |
| Model Number: | SIPZ-5H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 1000 PCS/Month |
|
Detail Information |
|||
| Name: | Hydraulic Conductor Reel Stands | Item No.: | 15151/ 15152 |
|---|---|---|---|
| Diameter: | 1250-2240mm/ 1250-2500mm | Max Plate Width: | 1400mm |
| Hole Diameter: | 80-125mm | Max Weight: | 5000/ 7000KG |
| Max Working Torque: | 1200/ 2000N.m | Max Speed: | 45rpm |
| Axle Diameter: | 76mm | Weight: | 270/ 350KG |
| Length Of Hydraulic Tube: | 13m | ||
| Highlight: | 1250mm Conductor Drum Stand,2240mm Conductor Drum Stand,Construction Hydraulic Drum Stand |
||
Product Description
Hydraulic Conductor Drum Stand For Construction Safety Tools
About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either
Hydraulic Conductor Reel Stands
| Item number | 15151 | 15152 | |
| Model | SIPZ-5H | SIPZ-7H | |
| Applicable reel | Diameter of coil (mm) | Φ1250～2240 | Φ1250～2500 |
| Max width of coil (mm) | 1400 | 1400 | |
| Diameter of axle hole (mm) | Φ80-125 | Φ80-125 | |
| Maximum weight (kg) | 5000 | 7000 | |
| Max working torque (N.m) | 1200 | 2000 | |
| Max Speed (rpm) | 45 | 45 | |
| Axle diameter | Φ76 | Φ76 | |
| Weight (kg) | 270 | 350 | |
| Length of hydraulic tube | 13 | 13 | |
Want to Know more details about this product
