Chain Type Handle Hoist Chain Pulley Block Transmission Line Stringing Tools 90KN
Product Details:
| Place of Origin: | Ningbo, China |
| Brand Name: | Suntech |
| Certification: | ISO9001 |
| Model Number: | Handle |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 1000 PCS/Month |
|
Detail Information |
|||
| Name: | Chaain TYpe Handle Hoist | Item No.: | 14201-14245 |
|---|---|---|---|
| Rated Load: | 5-90KN | Minimum Distance Between Hooks: | 260-700mm |
| Standard Lifting Height: | 1.5M | Number Of Lines Of Lifting Chain: | 1/2/3 Row |
| Weight: | 4.2-47KG | Weight Of 1m Chain: | 0.52-6.6KG |
| Warranty: | 1 Year | ||
| Highlight: | Chain Type Hoist Chain Pulley Block,Handle Hoist Chain Pulley Block,Transmission Line Stringing Tools 90KN |
||
Product Description
Chain Type Handle Hoist Chain Pulley Block Transmission Line Stringing Tools
About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either
Feature
Great Quality manual hand series lifting chain hoist block is light weight, suitable for simple manual operation and has a strong safety performance and high safety of the product performance, easy to use security; specifically designed for heavy industry, 360 ° rotating hand chain guide allowed operation from all angles, so that the operator can stay away from the danger zone.
| Item number | 14201 | 14211 | 14215 | 14221 | 14231 |
14241
|
14245 | |
| Rated load(KN) | 5 | 7.5 | 10 | 15 | 30 | 60 | 90 | |
| Minimum distance between hooks(MM) | 260 | 320 | 380 | 380 | 480 | 620 | 700 | |
| Standard Lifting Height(M) | 1.5 | |||||||
| Number of lines of Lifting Chain(row) | 1 | 1 | 1 | 1 | 1 | 2 | 3 | |
| Weight(KG) | 4.2 | 7.5 | 11.5 | 11.5 | 21 | 31.5 | 47 | |
| Item No. | 3m Length Of Chain | 14202 | 14212 | 14216 | 14222 | 14232 | 14242 | 14246 |
| 5m Length Of Chain | 14204 | 14214 | 14218 | 14224 | 14234 | 14244 | 14248 | |
| Weight of 1m chain(KG) | 0.52 | 0.8 | 1.4 | 1.4 | 2.2 | 4.4 | 6.6 | |
