750W Hydraulic Crimping Tools Single Double Stage Electric Hydraulic Pump
Product Details:
| Place of Origin: | Ningbo, China |
| Brand Name: | Suntech |
| Certification: | ISO9001 |
| Model Number: | ZCB6-5-AB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 1000 PCS/Month |
|
Detail Information |
|||
| Name: | Hydraulic Pump | Item No.: | 16153-1/ 16153-2 |
|---|---|---|---|
| Type: | Single-acting / Double-acting | Rated Output: | 750W |
| Voltage: | 220W/380W | Rated Pressure: | 70Mpa |
| Oil Capacity: | 8L | Frequency: | 50-60HZ |
| Weight: | 29/30KG | Package: | Wooden Case |
| Warranty: | 1 Year | ||
| Highlight: | 750W Hydraulic Crimping Tools,Hydraulic Crimping Tools Single Stage,Double Stage Electric Hydraulic Pump |
||
Product Description
Electric Hydraulic Pump Single Or Double Stage Hydraulic Pump Tools
About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All can accept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either.
Double speed high performance pumps, built in 10000Psi pressure overflow valve, can ensure the maximum
flow when maximum pressure.Standard of can see an oil window, observe the location of oil, with the normal operation that assures machine;
Equipped with low noise pure aluminum alloy enclosure motor and light weight, convenient to move.
Can choose to equip long range wire to control a switch, easy to long-distance to leave an operate
Use the following Suggestions 200 T of hydraulic cylinder
High and low speed two stage design is for quick oil output. Turbine oil absorption could ensure reaching max effective oil volume. Over pressure safety valve unit could avoid over pressure damage.At 700kg/cm2,automatically release.
Electric Hydraulic Pump Feature
1. Easy to operate and high safety
2.Precise Machining Technique
3. Long Life of the Machine
4.Delicate and Beautiful Appearance Design
5. Broader Applicable Scope
6.Good quality and less malfunction
| Item number | 16153-1/A | 16153-2/A | 16153-3 |
| Model | ZCB6-5-AB | ZCB6-5-A3 | ZCB6-5-ABC |
| Type | double-acting | single-acting | Three-acting |
| Rated Output | 750W/1500W | 750W/1500W | 1500W |
| Voltage | 220W/380W | 220W/380W | 220V/380V |
| Rated Pressure | 70MPa | 70MPa | 70MPa |
| Flow Rate | low pressure 2.5L/Min | lw pressure 2.5L/Min | lw pressure 2.5L/Min |
| high pressure0.52(1.7)L/min | high pressure0.52(1.7)L/min | high pressure1.7L/min | |
| Oil Capacity | 8L/30L | 8L/30L | 30L |
| Frequency | 50-60HZ | 50-60HZ | 50-60HZ |
| Weight(KG) |
approx.N.W26KG G.W30KG |
approx.N.W25KG G.W29KG |
approx.N.W37KG G.W40KG |
| Package | wooden case | wooden case | wooden case |
