Steel Pilot Wire High Strength Galvanized Shackle For Construction Works
Product Details:
| Place of Origin: | Ningbo, China |
| Brand Name: | Suntech |
| Certification: | ISO9001 |
| Model Number: | GXK-1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 1000 PCS/Month |
|
Detail Information |
|||
| Name: | High Strength Shackle | Item No.: | 17131-17139 |
|---|---|---|---|
| Rated Load: | 10-300KN | Weight: | 0.15-7.5KG |
| Warranty: | 1 Year | Uses: | Connecting Steel Rope With Loading Operation. |
| Highlight: | Steel Pilot Wire,Pilot Wire High Strength,Construction Works Galvanized Shackle |
||
Product Description
Steel Pilot Wire High Strength Galvanized Shackle For Construction Works In Transmission Line
About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either
Stringing Equipment High Strength Shackle
1. Rated load: 10~300kN
2. Weight: 0.15~7.5kgs
3. Material: High strength Steel
| Item number | Model |
Rated Load (KN) |
Main Size (mm) |
Weight (kg) |
|||
| A | B | C | D | ||||
| 17131 | GXK-1 | 10 | 55 | 42 | 12 | 20 | 0.15 |
| 17132 | GXK-2 | 20 | 67 | 58 | 16 | 22 | 0.29 |
| 17133 | GXK-3 | 30 | 97 | 82 | 20 | 34 | 0.80 |
| 17133A | GXK-3A | 30 | 97 | 112 | 20 | 34 | 0.80 |
| 17134 | GXK-5 | 50 | 107 | 89 | 22 | 39 | 1.12 |
| 17134A | GXK-5A | 50 | 107 | 131 | 22 | 39 | 1.29 |
| 17135 | GXK-8 | 80 | 125 | 96 | 30 | 42 | 2.40 |
| 17136 | GXK-10 | 100 | 141 | 114 | 34 | 48 | 3.56 |
| 17137 | GXK-16 | 160 | 152 | 139 | 37 | 54 | 4.80 |
| 17138 | GXK-20 | 200 | 164 | 140 | 39 | 60 | 5.17 |
| 17139 | GXK-30 | 300 | 186 | 146 | 50 | 68 | 7.5 |
