Transimission Line Pilot Steel Wire Rope Galvanized Anti Twisting Braided Steel Cable
Product Details:
| Place of Origin: | Ningbo, China |
| Brand Name: | Suntech Power |
| Certification: | ISO9001 |
| Model Number: | 12/18 Strand |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 M |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 10000M/ Month |
|
Detail Information |
|||
| Name: | Anti-Twisting Braided Steel Rope | Item No.: | 18117-18156 |
|---|---|---|---|
| Structure: | 12/18 Strand | Diameter: | 9-42mm |
| Breaking Force: | 54-817KN | Warranty: | 1 Year |
| Highlight: | Transimission Line Steel Wire Rope,Steel Wire Rope Galvanized,Anti Twisting braided steel cable |
||
Product Description
9-42mm Transimission Line Pilot Wire Galvanized Braided Anti Twisting Steel Wire Rope
Application
Applied to mechanical pulling and tensioning release conductors, unsuitable to pulling ropes for small diameter winch.It is braided 1960MPa high-strength galvanized steel wire.
Rotation resistance during pulling. Supple and disperse resistance.
Notes
The specification and length of steel can custom according to your request
Feature
Made of high strength galvanized steel wire.
It doesn't turn when it's turn round.Soft not broken strand.
| Item number | Structure | Diameter | Breaking Force | Weight |
| 18117 | 12 Strand | 9 | ≥54 | 0.3 |
| 18118 | 11 | ≥81 | 0.45 | |
| 18119 | 13 | ≥115 | 0.58 | |
| 18120 | 15 | ≥157 | 0.82 | |
| 18121 | 18 | ≥205 | 1.03 | |
| 18122 | 20 | ≥260 | 1.33 | |
| 18123 | 23 | ≥320 | 1.63 | |
| 18124 | 25 | ≥387 | 2.03 | |
| 18125 | 27 | ≥461 | 2.37 | |
| 18126 | 28 | ≥520 | 2.6 | |
| 18127 | 30 | ≥560 | 3.12 | |
| 18140 | 21 | ≥173 | 0.87 | |
| 18141 | 18 Strand | 24 | ≥236 | 1.24 |
| 18151 | 27 | ≥309 | 1.55 | |
| 18152 | 30 | ≥389 | 1.99 | |
| 18153 | 33 | ≥481 | 2.45 | |
| 18154 | 36 | ≥581 | 3.05 | |
| 18155 | 39 | ≥692 | 3.56 | |
| 18156 | 42 | ≥817 | 4.22 |
