54KN Handle Wire Rope Hoist Overhead Pilot Pulling Hoist Transmission Line Stringing Tools
Product Details:
| Place of Origin: | Ningbo, China |
| Brand Name: | Suntech |
| Certification: | ISO9001 |
| Model Number: | HSS408 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 1000 PCS/Month |
|
Detail Information |
|||
| Name: | Wire Rope Handle Hoist | Item No.: | 14183-14186 |
|---|---|---|---|
| Rated Lifting/ Pulling: | 8/12.5-54KN | Once Journey: | >40->20mm |
| Diametre Of Steel Rope: | 8.3-20mm | Standard Length Of Steel Rope: | 20M |
| Net Weight: | 6.8-52KG | Hand Wrenching At The Rate Load: | <343-<550N |
| Encasement Dimension: | 420x106x250-930x390x150mm | Warranty: | 1 Year |
| Highlight: | 54KN wire rope hoist,Handle wire rope hoist,54KN Transmission Line Stringing Tools |
||
Product Description
Wire Rope Handle Hoist Overhead Pilot Wire Rope Pulling Hoist Hand Winches
About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either
Explain:It has three functions of lifting,pulling and tensioning.It is suitable for long distance lifting or pulling in the field without power source.
| Item No. | 14183 | 14184 | 14185 | 14186 |
| Model | HSS408 | HSS416 | HSS432 | HSS454 |
| Rated Lifting/Pulling(KN) | 8/12.5 | 16/25 | 32/50 | 54 |
| Once journey(MM) | >=40 | >=40 | >=16 | >=20 |
| Diameter of steel rope(MM) | Φ8.3 | Φ11 | Φ16 | Φ20 |
| Standard length of steel rope(M) | 20 | 20 | 20 | 20 |
| Net weight(KG) | 6.8 | 13 | 25 | 52 |
| Hand wrenching at the rate load(N) | <=343 | <=400 | <=441 | <=550 |
| Encasement dimension(MM) | 420*106*250 | 530*126*315 | 660*160*360 | 930*390*150 |
