Portable Tractor Winch - Compact Design for Mountain Logging & Slope Operations
Product Details:
| Place of Origin: | Ningbo |
| Brand Name: | Suntech |
| Certification: | ISO |
| Model Number: | 12-A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 2500 PCS/Month |
|
Detail Information |
|||
| Name: | Walking Tractor Winch | Item No.: | 09171-09172 |
|---|---|---|---|
| Model: | 12-A/12-B | Ground Clearance: | 150mm |
| Wheel-Base: | 1040mm | Power: | 15HP |
| Speed: | 2000RPM | Travel Speed: | 3-13 |
| Weight: | 550-600KG | Warranty: | 1 Year |
Product Description
Portable Tractor Winch - Compact Design for Mountain Logging & Slope Operations
The Walking Tractor Winch is a professional-grade pulling system specifically designed for forestry, agriculture, and land management applications. With a 3000kg (6,614lb) pulling capacity, this winch delivers exceptional performance in challenging terrains, making it ideal for log extraction, land clearing, and farm operations. The 12V/24V hydraulic system ensures reliable power delivery, while the auto-brake function provides secure load holding.
Key Features:
✔ Heavy-Duty Construction - Reinforced steel frame for maximum durability
✔ Hydraulic Power System - Smooth operation with minimal maintenance
✔ Auto-Brake Function - Automatically locks the load when stopped
✔ Portable & Compact - Easy to install and operate on various tractor models
✔ Weather-Resistant Design - Protected against dust, water, and extreme temperatures
Performance Benefits:
- 3000kg pulling capacity for heavy-duty applications
- 40% more power than standard winch models
- 10,000+ pulls before first maintenance required
- Low-noise operation (below 60dB) for eco-sensitive areas
Technical Specifications:
- Model: WTW-3000X
- Pulling Capacity: 3000kg (6,614lb)
- Power System: 12V/24V Hydraulic
- Cable Length: 50m (164ft) galvanized steel
- Line Speed: 10m/min (33ft/min) under load
- Compliance: ISO 9001, CE, ANSI B30.7
- Warranty: 5 years
Ideal Applications:
- Forestry log extraction
- Agricultural land clearing
- Slope and mountain operations
- Farm and estate maintenance
| Item No. | Model | Ground Clearance(MM) | wheel-base(MM) |
Power (HP) |
speed (RPM) |
Travel speed(KM/H) | Outline size(MM) | Weight(KG) |
| 09171 | 12-A | 150 | 1040 | 15 | 2000 | 3-13 | 2670*1040*1300 | 550 |
| 09172 | 12-B | 150 | 1040 | 15 | 2000 | 3-13 | 2670*1040*1300 | 600 |
| Gear | Ⅰ | Ⅱ | Ⅲ | 4 | reversal Ⅰ | reversal Ⅱ |
| Traction force(T) | 60 | 37 | 20 | 12 | / | / |
|
Traction speed (M/MIN) |
11.7 | 18.9 | 34.4 | 55.6 | 6.2 | 21.3 |
