High-Efficiency Tractor-drawn Winch - 50% More Power Than Standard Winch Models
Product Details:
| Place of Origin: | Ningbo |
| Brand Name: | Suntech |
| Certification: | ISO |
| Model Number: | SX4-V1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 2000 PCS/Month |
|
Detail Information |
|||
| Name: | Tractor-drawn Winch | Item No.: | 08126 |
|---|---|---|---|
| Model: | XS4-V1 | Traction Force: | 20-40KN |
| Traction Speed: | 11-38M/Min | Bottom Of Groove Diameter: | 300mm |
| Number Of Groove: | 6 | Weight: | 1740KG |
| Outline Size: | 2900x14000x1440mm | Warranty: | 1 Year |
Product Description
High-Efficiency Tractor-drawn Winch - 50% More Power Than Standard Winch Models
The Tractor-drawn Winch is a heavy-duty pulling system specifically engineered for agricultural, forestry, and land management operations. With an impressive 5000kg (11,023lb) pulling capacity, this winch delivers exceptional performance in demanding field conditions. The hydraulic/PTO dual-power system ensures versatile operation, while the auto-brake function provides secure load control.
Key Features:
✔ Dual-Power Operation - Compatible with both hydraulic systems and tractor PTO shafts
✔ Heavy-Duty Construction - Reinforced steel frame with anti-corrosion coating
✔ Auto-Brake System - Automatically locks the load when stopped
✔ Easy Installation - Universal mounting system fits most tractor models
✔ Weatherproof Design - IP65-rated for all-weather operation
Performance Benefits:
- 4000kg pulling capacity for heavy-duty applications
- 50% more power than standard winch models
- 15,000+ pulls before first maintenance required
- Low-noise operation (below 65dB) for minimal disturbance
Technical Specifications:
- Model: SX4-V1
- Pulling Capacity: 4T
- Power Options: Hydraulic (200bar) / PTO (540/1000rpm)
- Cable Length: 60m (197ft) galvanized steel
- Line Speed: 12m/min (39ft/min) under load
- Compliance: ISO 9001
- Warranty: 1 years
Ideal Applications:
- Agricultural field operations
- Forestry log extraction
- Land clearing and rehabilitation
- Heavy equipment recovery
Specifications:
|
Item number |
08126 |
Power |
22KW |
Model | SX4-V1 | |
| Gear | Ⅰ | Ⅱ |
Ⅲ |
reversalⅠ | ||
| Traction force(KN) | 40 | 30 |
20 |
- | ||
| Traction speed(M/MIN) | 12 | 21 |
38 |
11 | ||
| bottom of groove diameter | Φ300mm | |||||
| Number of groove | 6 | |||||
| Weight(KG) | 1740kg | |||||
| outline size | 2900x14000x1440mm | |||||
