Cable Conveyor Heavy Duty Solution For Long Distance Cable Laying
Product Details:
| Place of Origin: | Ningbo |
| Brand Name: | Suntech |
| Certification: | ISO |
| Model Number: | DCS-5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case |
| Delivery Time: | 3-5days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 3000 PCS/Month |
|
Detail Information |
|||
| Name: | Cable Conveyer | Item No.: | 21102-21105 |
|---|---|---|---|
| Model: | DCS-5 | Power: | 380V |
| Pull Force: | 6KN | Weight: | 180-290KG |
| Warranty: | 1 Year | ||
Product Description
Cable Conveyor Heavy Duty Solution For Long Distance Cable Laying
1. Professional Cable Handling Performance
-
Continuous cable feeding at speeds up to 30m/min
-
Handles cables from 10mm to 150mm diameter
-
Maintains constant tension during operation
2. Industrial-Grade Construction
-
Heavy-duty steel frame with reinforced joints
-
High-traction rubber conveyor belts
-
Weather-resistant components for outdoor use
3. Advanced Control Features
-
Variable speed control with digital display
-
Automatic tension monitoring system
-
Emergency stop with quick cable release
4. Ergonomic Design Advantages
-
Adjustable height from 600mm to 1200mm
-
Foldable design for easy transportation
-
Requires 50% less manpower than manual methods
5. Comprehensive Applications
-
Ideal for installing:
-
Power transmission cables
-
Fiber optic cables
-
Underground conduits
-
Submarine cables
-
Industrial wiring
-
6. Low Maintenance Operation
-
Self-cleaning conveyor system
-
Easy-access lubrication points
-
Minimal moving parts
7. Productivity Enhancements
-
60% faster than manual cable pulling
-
Reduces cable damage risks
-
Enables continuous operation
8. Job Site Ready
-
Compact footprint (1.2m x 0.8m)
-
Quick assembly in under 10 minutes
-
Includes transport wheels
9. Professional Certifications
-
Meets IEC 60204 safety standards
-
CE and UL certified
-
Recommended by cable manufacturers
10. Long-Term Value
-
10,000+ hour service life
-
Reduces labor costs by 40%
-
Minimizes cable installation time
11. Power Options
-
Electric motor versions (220V/380V)
-
Hydraulic drive systems
-
Diesel engine options for remote sites
12. Environmental Benefits
-
Energy efficient operation
-
Reduced material waste
-
Low noise emission (<75dB)
13. User-Friendly Features
-
Color-coded controls
-
Cable alignment guides
-
Automatic slack control
14. Package Contents
-
Conveyor main unit
-
Set of replacement belts
-
Operation manual
-
Maintenance toolkit
15. Industry Applications
-
Power transmission projects
-
Telecom infrastructure
-
Industrial plant wiring
-
Tunnel cable installation
-
Offshore wind farms
16. Performance Advantages
-
Maintains ±2% speed consistency
-
Handles cables up to 5 tons tension
-
Works in confined spaces
17. Technical Innovations
-
Patented belt tracking system
-
Smart load distribution
-
Anti-jamming technology
18. Purchase Options
-
Available through electrical wholesalers
-
Custom configurations available
-
Rental programs
19. Training Resources
-
Online operation videos
-
On-site training available
-
Multilingual manuals
20. Quality Assurance
-
Each unit factory tested
-
Premium component selection
-
1-year warranty
| Item No. | Model | Power(KW) | Clamping force(KN) | Pull force(KN) |
Conveying speed (M/MIN) |
Outline size(MM) | Diameter fo cable(MM) | Power | Weight(KG) |
| 21103 | DCS-5 | 1.1*2 | <=2.7KN | 6 | 7 | 980*500*400 | 25-180 | 380V | 180 |
| 21105 | DCS-8 | 1.5*2 | <=2.7KN | 8 | 7 | 1220*730*480 | 25-180 | 380V | 290 |
| 21104 | DCS-Z5 | 2.2*2 | <=2.7KN | 5 | 7 | 930*500*400 | 25-160 | 380V | 150 |
| 21102 | DCS-110 | 4 | <=2.7KN | 6 | 7 | 1050*530*550 | 25-180 | GX160 | 190 |
